Formatic Burger Machine - S2000-180 stacker stacks burgers up to a total height of 100mm tall.

• External Dimensions (WxDxH) 780x795x710mm
• Throughput 4000/hr (variable)
• Power 1.1kW (1 phase)
• Hopper 45 litre
• Max diameter 135mm
• Stacks burgers
• 6 burgers stacked - thickness of burger no more than 15mm each
• 5 burgers stacked - thickness of burger no more than 20mm each
• 4 burgers stacked - thickness of burger no more than 24mm each
• Overall total stacking height is Approx 100mm.

N.B Compressed air required to run this machine, this is used for the auto wire cleaning mechanism

The Formatic S2000-180 stacker burger machine is the commercial version that will stack up to 4000 burgers per hour. The commercial line of burger machines from Formatic feature stronger motors, wider burger drums (for bigger diameter burgers) maximum diameter of 135mm.

The Formatic S2000-180 Stacker is fitted with a twin form drum standard depth , which is adjustable between 6-24mm in depth. The option of having a deeper drum is available at an additional costs if required, that would be adjustable between 6-34mm. The S4000 machine is fitted as standard with an extended conveyor belt which is 1m in length, a 45 litre hopper with a swivel lid that is fitted with safety magnet that stops the machine from working when the lid is opened. The machine is also fitted with auto wire clean (compressed air required) and auto paper attachment.

For more information about this machine please call our sales dept on 0161 366 1777 or download the brochure below.
